Passive control of indoor humidity with wooden materials
Vinogradova, Nataliia (2023)
Vinogradova, Nataliia
2023
All rights reserved. This publication is copyrighted. You may download, display and print it for Your own personal use. Commercial use is prohibited.
Julkaisun pysyvä osoite on
https://urn.fi/URN:NBN:fi:amk-202305047780
https://urn.fi/URN:NBN:fi:amk-202305047780
Tiivistelmä
This thesis investigates if the moisture buffering effect of wooden materials can stabilize
indoor humidity by using a case study of an administrative building. This work was done for
the PUUSTA project (Welfare Innovations from Wood).
The simulations have been carried out in IDA ICE. The HMWall model developed by EQUA
was used to simulate the moisture buffering effect in structures. During the research,
guidelines and advice from HMWall developer were used to run the simulation correctly.
The entire simulation environment has been established and described. Three simulation
cases were performed. These cases were chosen to find out if replacing walls with the new
model (thereby adding the moisture buffering effect) has an impact on the results.
It was concluded that the humidity flux through the structure during the summer is 4 times
higher than the values in winter. It shows that the work of HMwall is correct and does not
conflict with the theory. It was also noticed that the largest amplitude of humidity flux for
January is observed at the internal wall with the largest area and is 5.4·10(-7) kg/s. In July,
the greatest amplitude is observed at the external wall with the largest area and is
22.6·10(-7) kg/s.
Occupants, lighting, or equipment activity had almost no impact on the increase or
decrease in the humidity in the room at the scale of the simulation. This was observed both
at the level of the working week and at the level of the working day.
After a comparison of simulation cases, it can be concluded that according to the results,
there is an impact of moisture buffering on humidity, but it is extremely small. Humidity
peaks decreased by approximately 1% or less, which is almost imperceptible to humans.
